LA8

*  Specification

LA8MH

LA8MH/A

LA18B/A

Type

8", 2-Way Fullrange, Linearray system

8", 2-Way Fullrange, Linearray system

2X18" Bass reflex sub-woofer

Frequency Range(-10dB)

50Hz~20KHz

50Hz~20KHz

40Hz~290Hz

Frequency Response(+3dB)

60Hz~18KHz

60Hz~18KHz

45Hz~280Hz

Coverage pattern

100°Hx 20°V nominal

100°Hx 20°V nominal

Omni

Sensitivity(1W/1m) (SPL)

99 dB

99 dB

103 dB

Sensitivity Max.(SPL)

128 dB

128 dB

137 dB

Power Rating (Continous/Program/Peak)

400  / 800 / 1600 watts

400  / 800 / 1600 watts

1600  / 3200 / 6400 watts

Nominal Impedance

16 Ohms

16 Ohms

4 Ohms

Input Connectors

2XNutrik ® Speakon, NL4 ,  1+ / 1- (Linked from input to output)

XLR/Input & Output

Crossover Mode

Passive

Active

Active

Crossover Frequency

2.4 kHz

2.4 kHz

Drivers

2x8" / 2x1"

2x8" / 2x1"

2x18"

Enclosure

15mm Plywood

15mm Plywood

18mm Plywood

Appearance Finish

Polyurea Coating

Polyurea Coating

Polyurea Coating

Dimensions (W×H×D)

600X292X450mm

600X292X450mm

1170X610X760mm

Package(W×H×D):

650X340X495mm

650X340X495mm

1230X645X810mm

Q''ty for package

1 PCS / 1 CTN

1 PCS / 1 CTN

1 PCS / 1 CTN

Weight (Kg)

22.5

25

84
