Specification
|
OP-2400TOP
|
OP-2400 TOP/A
|
|
Type
|
12" , 2-Way Fullrange System
|
12" , 2-Way Fullrange System
|
|
Frequency Range(-10dB)
|
50Hz~20kHz
|
50Hz~20kHz
|
|
Frequency Response(+3dB)
|
65Hz~19kHz
|
65Hz~19kHz
|
|
Coverage pattern
|
90°H X 60°V nominal
|
90°H X60°V nominal
|
|
Sensitivity(1W/1m) (SPL)
|
98 dB
|
98 dB
|
|
Sensitivity Max.(SPL)
|
127 dB
|
127 dB
|
|
Power Rating (Continous/Program/Peak)
|
400 / 800 / 1600 watts
|
400/ 800 / 1600 watts
|
|
Nominal Impedance
|
8 Ohms
|
8 Ohms
|
|
Input Connectors
|
2XNutrik ® Speakon, NL4 , 1+ / 1- (Linked from input to output)
|
/
|
|
Crossover Mode
|
Passive
|
/
|
|
Crossover Frequency
|
1.8 kHz
|
1.8 kHz
|
|
Drivers
|
HF: CSR150D/SUIM X 1, LF: HQ12 / SUIM X 1
|
HF: CSR150D/SUIM X 1, LF: HQ12 / SUIM X 1
|
|
Enclosure
|
15mm Plywood
|
15mm Plywood
|
|
Appearance Finish
|
Water-borne (Green Eco), Sand texture painting (4 times)
|
Water-borne (Green Eco), Sand texture painting (4 times)
|
|
Dimensions (W×H×D)
|
385X620X400
|
385X620X400
|
|
Package(W×H×D):
|
445X660X435
|
445X660X435
|
|
Q'ty for package
|
1 PCS / 1 CTN, Inner and outer carton, double package.
|
1 PCS / 1 CTN, Inner and outer carton, double package.
|
|
Weight (Kg)
|
24
|
26.5
|
|
Suspensive/Mounting
|
35mm tube socket, M8 X 10 Screw nuts for U-Bracket or wire flying.
|
35mm tube socket, M8 X 8 Screw nuts for U-Bracket or wire flying.
|
|
* Specification
|
OP-2400 SUB
|
OP-2400 SUB/A
|
|
Type
|
18" , Bass reflex type
|
18" , Bass reflex type
|
|
Frequency Range(-10dB)
|
40Hz~270Hz
|
40Hz~270Hz
|
|
Frequency Response(+3dB)
|
47Hz~240kHz
|
47Hz~240kHz
|
|
Coverage pattern
|
Omni
|
Omni
|
|
Sensitivity(1W/1m) (SPL)
|
102 dB
|
102 dB
|
|
Sensitivity Max.(SPL)
|
133 dB
|
133 dB
|
|
Power Rating (Continous/Program/Peak)
|
800 / 1600 / 3200 watts
|
800 / 1600 / 3200 watts
|
|
Nominal Impedance
|
8 Ohms
|
8 Ohms
|
|
Input Connectors
|
2XNutrik ® Speakon, NL4 , 1+ / 1- (Linked from input to output)
|
/
|
|
Drivers
|
LF: HQ18S / SUIM X 1, 4" Voice Coil
|
LF: HQ18S / SUIM X 1, 4" Voice Coil
|
|
Enclosure
|
18mm Plywood
|
18mm Plywood
|
|
Appearance Finish
|
Water-borne (Green Eco), Sand texture painting (4 times)
|
Water-borne (Green Eco), Sand texture painting (4 times)
|
|
Dimensions (W×H×D)
|
550X735X625
|
550X735X625
|
|
Package(W×H×D):
|
670X775X590
|
670X775X590
|
|
Q'ty for package
|
1 PCS / 1 CTN, Inner and outer carton, double package.
|
1 PCS / 1 CTN, Inner and outer carton, double package.
|
|
Weight (Kg)
|
45
|
51
|
|
* Technical Data for Amp. Module
|
OP-2400 TOP/A
|
OP-2400 SUB/A
|
|
Output Power
|
500W RMS
|
1000W RMS
|
|
Input Type
|
Balanced differential
|
Balanced differential
|
|
Input Impedance
|
33K Ohms
|
33K Ohms
|
|
Input Sensitivity
|
Line: 0 dBV
|
Line: 0 dBV
|
|
LED Indicators
|
Signal Overload
|
Signal Overload
|
|
Rated THD
|
<0.007%
|
<0.007%
|
|
Line Connectors
|
Line: XLR
|
Line: XLR
|
|
Output Connectors
|
Line Loop Thru: XLR / Male
|
Line Loop Thru: XLR / Male
|
|
Operation Voltage
|
~100-120V or ~220-240v
|
~100-120V or ~220-240v
|
