Specification
|
RQM10/10A
|
RQM12/12A
|
RQM15/15A
|
|
Type
|
10" , 2-Way Fullrange, Multi-function type.
|
12" , 2-Way Fullrange, Multi-function type.
|
15" , 2-Way Fullrange, Multi-function type.
|
|
Frequency Range(-10dB)
|
60Hz~18kHz
|
60Hz~18kHz
|
50Hz~18kHz
|
|
Frequency Response(+3dB)
|
70Hz~17kHz
|
70Hz~17kHz
|
60Hz~17kHz
|
|
Coverage pattern
|
90°H X 60°V nominal
|
60°H X 40°V nominal
|
60°H X 40°V nominal
|
|
Sensitivity(1W/1m) (SPL)
|
96 dB
|
98 dB
|
101 dB
|
|
Sensitivity Max.(SPL)
|
121 dB
|
124 dB
|
129 dB
|
|
Power Rating (Continous/Program/Peak)
|
150 / 300 / 600 watts
|
200 / 400 / 800 watts
|
300 / 600 / 900 watts
|
|
Nominal Impedance
|
8 Ohms
|
8 Ohms
|
8 Ohms
|
|
Input Connectors
|
2XSpeakon, NL4, 1+ / 1- (Linked from input to output)
|
2XSpeakon, NL4, 1+ / 1- (Linked from input to output)
|
2XSpeakon, NL4, 1+ / 1- (Linked from input to output)
|
|
Crossover Mode
|
Passive
|
Passive
|
Passive
|
|
Crossover Frequency
|
3 kHz
|
3.5 kHz
|
3 kHz
|
|
Drivers
|
HF: 1X1" / LF: 10"x1
|
HF: 1X1" / LF: 12"x1
|
HF: 1X1" / LF: 15"x1
|
|
Enclosure
|
15mm Plywood
|
15mm Plywood
|
18mm Plywood
|
|
Appearance Finish
|
Water-borne (Green Eco), Sand texture painting (4 times)
|
Water-borne (Green Eco), Sand texture painting (4 times)
|
Water-borne (Green Eco), Sand texture painting (4 times)
|
|
Dimensions (W×H×D)
|
335X500X305
|
385X565X345
|
432X690X375
|
|
Package(W×H×D):
|
385X545X350
|
425X615X385
|
485X735X415
|
|
Q'ty for package
|
1 PCS / 1 CTN, Inner and outer carton, double package.
|
1 PCS / 1 CTN, Inner and outer carton, double package.
|
1 PCS / 1 CTN, Inner and outer carton, double package.
|
|
Weight (Kg)
|
14/15
|
18/19
|
25.5/27
|
|
Suspensive/Mounting
|
35mm tube socket, M8 X 3 Screw nuts for U-Bracket or wire flying.
|
35mm tube socket, M8 X 3 Screw nuts for U-Bracket or wire flying.
|
35mm tube socket, M8 X 3 Screw nuts for U-Bracket or wire flying.
|
|
Technical Data for Amp. Module
|
RQM10A
|
RQM12A
|
RQM15A
|
|
Output Power
|
250W RMS
|
350W RMS
|
500W RMS
|
|
Input Type
|
Balanced differential
|
Balanced differential
|
Balanced differential
|
|
Input Impedance
|
20K Ohms
|
20K Ohms
|
20K Ohms
|
|
Rated THD
|
<0.03%
|
<0.03%
|
<0.03%
|
|
Line Connectors
|
Line: XLR
|
Line: XLR
|
Line: XLR
|
|
Output Connectors
|
Line Loop Thru: XLR / Male; Mic. Input: Combo Jack
|
Line Loop Thru: XLR / Male; Mic. Input: Combo Jack
|
Line Loop Thru: XLR / Male; Mic. Input: Combo Jack
|
|
Operation Voltage
|
~100-240V
|
~100-240V
|
~100-120V or ~220-240v
|
